ASTRO – 33

Collaborative robot (Cobot)

Why Astro-33?

This Astro-33 is the smallest collaborative cell of our product line. Its size covers smaller floor space than classic industrial robots, which makes it perfect for smaller plants that would like to automate their production lines. Also, this entry-level cell is the least expensive of our cobots cells. This makes the Astro33 the perfect product to start automating a factory and try a cobot for the first time.

Like every collaborative cell, the Astro-33 can safely work closely with human workers. This small cell is perfect for tasks with lighter payload like pick-and-place, material sorting, or any other repetitive task.

Astro-33 CRX 10iA

Get the best fit for your automation project with one of our robotic cells.

This robotic cell finder will help you find the perfect cell to improve your production line. If you have trouble identifying your needs, we’ll be glad to help.

Filter products Showing all 27 results
Reach (mm)
Payload (kg)
Product Speed
Category

APPLICATIONS

Icone_PickandPlace

Pick-and-place

When it comes to pick and place tasks, the Astro-33 can be equipped with different technologies to identify, grasp, and move objects from one place to another. The FANUC Robot can easily be configured for different paths and various end-of-arm tooling options.

Material Sorting

Material sorting

The Astro-33 has the advantage of being mobile and modular, so it can be tailored to optimize the tasks in question. The FANUC Robot is also simple to integrate and therefore, the Robotic paths can be easily adjusted to your needs.

Repetitive Task

Repetitive tasks

Collaborative robots are the perfect solution for repetitive tasks. They are more accurate than humans and can work hours without any interruption. The versatility of the Astro-33 allows it to fit multiple different repetitive tasks within your production lines.

Astro-33 CRX 10iAL

BENEFITS

easytoprogram icon
EASY-TO-PROGRAM
Icon Pre engineered
PRE-ENGINEERED
easytoprogram icon
SAFE
Icon Customazible
CUSTOMIZABLE
easytoprogram icon
PLUG-AND-PLAY

This low-cost cobot comes with the usual DIY Robotics advantages such as
modularity, mobility, and free support.

ROBOTIC COMPATIBILITY OPTIONS

Starting at
$77,500 USD

Astro-33 CRX 10iA
timer - icon

1000 mm/s

largeur icon

1249 mm

kg icon

10 kg

  • Weight : 261 kg (575 lbs)
  • Wheels with integrated leveling pads
  • Integrated electrical cabinet (32 in/32 out available user I/O)
  • Integrated pneumatic panel (4 valves 5/3 open-center 6 mm ports)
  • Meets the CSA requirements
  • Easily adaptable for custom needs
  • Optional adjustable height for improved ergonomics
    (Electrically or mechanically):

    • Min 30 in (762 mm)
    • Max 38 in (965 mm)
  • 200-240 VAC single phase:
    • Optional 120V 15A
  • EtherNet/IP communication
  • Karel
  • DCS
  • Basic interference check
  • Collision Guard
  • Constant Path

Included software :

  • Background logic programs for alarms, lights, locking sequence, and timers for the general operation of the robotic cell
  • 10 basic programs associated with the product selection on the HMI page
  • The cell is programmed to be operated with 3 buttons (Stop, Reset, Start). It starts a main program that calls the selected product
  • One homing program selectable by a macro
  • Two HMI pages; one for the general operation of the cell and one for the product selection
Astro-33

Installation

The Astro Cell can be integrated into your production line with only 5 simple steps. Before the Astro-33 arrives at your factory, make sure its space has been prepared. The floor does not need to be perfectly leveled, as you will be able to adjust the cell by handling the pre-integrated ratchet handles on the wheels. The Astro cell needs an electric and a pneumatic connection. Make sure you have both of them set up. You can find more specifications about the Astro-33 installation procedure on the documentation shared on our website. Remember that DIY Robotics provides free support to help you at any moment if needed.

Turnkey solution

If you’re not comfortable installing and integrating the collaborative cell yourself, know that we partner with plenty of official integrators that can help turn our plug-and-play robotic cells into a turnkey solution that fits your needs. We can recommend a partner for your project, or you can pick one yourself according to your preference, on our turnkey solution page.

We can assist you in many ways

As our mission is to make industrial robotics accessible to all, we have developed several tools to guide you towards your own Industrial Revolution. Visit our forum for free programming, engineering, designing, and troubleshooting support. You can also use our 3D builder to create a cell that fits your specific needs, and use our payload calculator to make sure the robot you selected can manipulate the EOAT you designed.
